HW
Commercial Ceiling Heater
TPI

Commercial Ceiling Heater

E3383DRP
Price $975.00 $624.00
SKU: E3383DRP
BTU /hr.: 5120 BTU
Fuel Type: Electric
Volts: 120 V
Color: White
Brand: TPI
Resources

TPI Commercial Ceiling Heater 5120 Btu E3383DRP Resources:

TPI Commercial Ceiling Heater 5120 Btu E3383DRP Specifications

The best way to keep things warm is electric forced air heaters made by the reputed brand TPI. Model E3383DRP is Commercial Ceiling Heater that gives you an excellent 5120 Btu capacity. The model features with vane axial fan blade 1.5kw - 4.0kw units, 700 RPM motor, 175 CFM 4.8kw units and 900 RPM motor. This unit comes with steel block fin element and Automatic reset thermal limit. Optional factory installed thermostat included.

Commercial Ceiling Heater - 5120 Btu - TPI E3383DRP Specifications
KW 1.5
BTU'S 5120
Volts 120
PH 1
AMPS 12.5
TEMP RISE 27 Deg F
Dimensions 14-3/16" W x 19-15/16" H x 4" D
UPC 686334366489

1500 W Commercial Ceiling Heater - 5120 BTU - TPI E3383DRP Features:

  • Fan purge circuit (requires 4 wire supply when remote wall thermostat is used with the unit)
  • Disconnect switch
  • Optional factory installed thermostat
  • White powder coated 18 ga. steel grill
  • Manual reset thermal limit
  • Steel block fin element
  • Vane axial fan blade: 700 RPM motor; 175 CFM
  • Weight 22 lbs.
  • Rough in dimensions: 14 3/16" wide x 19 5/16" high x 4" deep
  • Grill dimensions - 15 3/8" wide x 20 9/64" high
  • ETL listed
