HW
Commercial Fan Forced Wall Heater
TPI

Commercial Fan Forced Wall Heater

HF3323TDRP
Price $447.15
Please select from the Options below
Factory Installed Controls
SKU: HF3323TDRP
BTU /hr.: 3840 - 5120 BTU
Fuel Type: Electric
Volts: 208 - 240 V
Color: Silver / Black
Brand: TPI
Resources

TPI Commercial Fan Forced Wall Heater HF3323TDRP Resources:

TPI Commercial Fan Forced Wall Heater HF3323TDRP Specifications

1500 / 1125 W, 5120 / 3840 BTU Commercial Fan Forced Wall Heater with Single Pole Thermostat is manufactured by TPI. Model HF3323TDRP features disconnect switch, automatic fan delay circuit and powder coated 18ga. steel grill with extruded aluminum front frame. It ensures best performance at maximum ease.

Commercial Fan Forced Wall Heater - TPI HF3323TDRP Specifications
BTU5120 / 3840
Wattage1500 / 1125 W
Voltage240 / 208 V
Product Weight26 Lbs.
Product Dimensions14-3/16"W x 4"D x 19-15/16"H
CFM175
Amperage6.2 / 5.4
UPC686334380942

Commercial Fan Forced Wall Heater - TPI HF3323TDRP Features:

  • Disconnect switch
  • Automatic fan delay circuit
  • Powder coated 18ga. steel grill with extruded aluminum front frame
  • Automatic reset thermal limit
  • Steel block fin element
  • Vane axial fan blade: 600 RPM
  • 50 - 90 F temperature range
  • Grill dimensions - 15-29/32" wide x 20-27/32" high
  • cETLus listed
