Fan Forced Ceiling Heater
TPI

Fan Forced Ceiling Heater

H3032DWBW
Price $178.20
SKU: H3032DWBW
BTU /hr.: 6826 BTU
Fuel Type: Electric
Volts: 208 - 240 V
Color: White
Brand: TPI
Resources

TPI Fan Forced Ceiling Heater H3032DWBW Resources:

TPI Fan Forced Ceiling Heater H3032DWBW Specifications

Heaters - 750-2000W 208 / 240V 12-1/8" Fan Forced Ceiling Heater - 6826 BTU - White - TPI H3032DWBW

Get best deals on Heaters made by TPI. Model H3032DWBW is 12-1/8" high Fan Forced Ceiling Heater that delivers 6826 BTU output by consuming 750-2000W and 208 / 240V. This white color model has selectable wattage at time of installation. This model has Powder coated 18 ga. steel front and manual reset thermal limit.

12-1/8" Fan Forced Ceiling Heater - White - TPI H3032DWBW Specifications
Watts750 or 1000 - 1500 or 2000
BTU'S6826
VOLTS208 / 240
AMPS8.3
Weight6 Lbs.
Dimension9-1/4" W x 12-1/8" H x 3-5/8" D
UPC686334948883

12-1/8" Fan Forced Ceiling Heater - White - TPI H3032DWBW Features

  • Wattage selectable at time of installation - models shipped wired to highest wattage
  • Fan purge circuit (requires 4 wire supply when remote single pole wall thermostat is used with the unit)
  • Models may not be used with remote double pole thermostat
  • Drywall depth embossments on back can
  • Powder coated 18 ga. steel front
  • Manual reset thermal limit
  • Steel block fin element
  • Propeller style fan blade - 1060 RPM / 100 CFM
  • Optional field installed control voltage relays available
  • Rough in dimensions - 9 1/4" wide - 12 1/8" high - 3 5/8" deep
  • Grill dimensions: 9 25/32" wide - 13" high
  • UL listed
Accessories
24V Relay
TPI
Price $25.30
120V Relay
TPI
Price $25.30
208 / 240V Relay
TPI
Price $26.40
277V Relay
TPI
Price $26.40
1" Extender
TPI
Price $29.15
2" Extender
TPI
Price $29.70
T-Bar Frame
TPI
Price $41.25
