Fan Forced Suspended Unit Heater
TPI

Fan Forced Suspended Unit Heater

P3P5107CA1N
Price $837.10
Please select from the Options below
Control Option
SKU: P3P5107CA1N
BTU /hr.: 25600 BTU
Fuel Type: Electric
Volts: 480 V
Color: Ivory
Brand: TPI
Resources

TPI Fan Forced Suspended Unit Heater P3P5107CA1N Resources:

TPI Fan Forced Suspended Unit Heater P3P5107CA1N Specifications

7.5 KW 5100 Series Fan Forced Suspended Unit Heater is one of the best quality product by TPI , that assures long term investment and relief in winters. Model P3P5107CA1N has 18 ga. steel cabinet with powder coated finish. This unit comes with in-built temperature control thermostats - low or line voltage. This multi featured unit is worth investing unit.

TPI Fan Forced Suspended Unit Heater - P3P5107CA1N Specifications
Wattage7.5 KW
BTU's25.6 BTU/H
VOLTS480V
Phase3 Ph
AMPS9.1
Control Voltage24
Temp Rise deg F34 F
Air Throw22'
CFM700
Recom'd Mounting Ht.Hor- 10', Ver- 12'
Dimension24-5/16"H x 21-1/2"W x 6-1/2"D
Weight54 lbs.
UPC686334645249
ListedETL Listed

Fan Forced Suspended Unit Heater - P3P5107CA1N Features:

CONSTRUCTION:

  • 18 ga. Steel cabinet with powder coated finish and control compartment housing a master terminal board with a hinged and latched access door, simplifying wiring, installation & maintenance

HEATING ELEMENT:

  • Spiral fin steel element with continuously brazed steel fins formed to allow side draw through air flow

OVERHEAT PROTECTION:

  • 3.3 - 50 KW units come equipped with automatic reset type limit

FAN and MOTOR:

  • Totally enclosed, 1-speed, 1-phase, permanently lubricated, thermally protected motors with unit bearings on 3 KW - 20 KW models

LOUVER ASSEMBLY:

  • Louvers are individually adjustable for directional control of air flow up to 15 deg from straight horizontal
  • Optional diffusers available for down flow (vertical discharge) applications

TEMPERATURE CONTROLS:

  • Optional low voltage and line voltage thermostats available with an adjustable temperature range of 50 deg -90 deg F
  • Units with model numbers ending in CA1 are factory wired for low voltage controls

INSTALLATION:

  • Unit Heaters can be mounted for horizontal or vertical discharge
  • 5100 series suggested for applications up to 6000 feet; for applications up to or above 6000 feet see UH series.

FIELD INSTALLED OPTIONS:

  • In-Built or wall mounted temperature control thermostats - low or line voltage
  • Summer fan switch to operate the fan only.
  • Power disconnect switch
  • 60-100KW units can be multiple stage when used with optional SC5100 and C1025 stat
  • Heat stratification thermostat
