Fan Forced Wall Heater
TPI

Fan Forced Wall Heater

F30522T2DWB
Price $249.15
SKU: F30522T2DWB
BTU /hr.: 7680 BTU
Fuel Type: Electric
Volts: 208 V
Color: Silver / Black
Brand: TPI
Resources

Commercial Fan Forced Wall Heater TPI F30522T2DWB Resources:

Commercial Fan Forced Wall Heater TPI F30522T2DWB Specification

Fan Forced Wall Heaters - Commercial Fan Forced Wall Heaters w/ Selectable Wattages & DP Thermostat - TPI F30522T2DWB - 7680 BTU

Commercial Fan Forced Wall Heaters With Selectable Wattages & DP Thermostat is the right heater for the right job. This TPI model F30522T2DWB is approved for horizontal mounting - right or left discharge. It is constructed using best quality 18 ga. powder coated steel & extruded aluminum front. This multi feature unit has Propeller style fan blade with manual reset thermal limit.

Commercial Fan Forced Wall Heater TPI F30522T2DWB Specifications
UPC686334945691
Max BTU's7680
Wattage500 or 750 or 1000 or 1250 or 1500 or 1750 or 2250
Volts208
Max. Amps10.8
Dimensions9-1/4" W x 12-1/8" H x 3-5/8"D

Commercial Fan Forced Wall Heater TPI F30522T2DWB Features:

  • Wattage selectable at time of installation - models shipped wired to highest wattage
  • Approved for horizontal mounting - right or left discharge
  • Fan purge circuit
  • Disconnect switch
  • Drywall depth embossments on back can
  • 18 ga. powder coated steel & extruded aluminum front
  • Manual reset thermal limit
  • Steel block fin element
  • Propeller style fan blade: 1060 RPM motor; 100 CFM
  • Weight 6 lbs.
  • Rough in dimensions - 9-1/4" W x 12-1/8" H x 3-5/8"D
  • Grill dimensions - 10" wide x 13 1/8" high
Accessories
1" Extender
TPI
Price $29.70
2" Extender
TPI
Price $30.25
