Fan Forced Unit Heater
TPI

Fan Forced Unit Heater

F3F5115CA1L
Price $1,376.65
Please select from the Options below
Control Option
SKU: F3F5115CA1L
BTU /hr.: 51200 BTU
Fuel Type: Electric
Volts: 208 V
Color: Ivory
Brand: TPI
Resources

TPI 15 KW Suspended Fan Forced Unit Heater F3F5115CA1L Resources:

TPI 15 KW Suspended Fan Forced Unit Heater F3F5115CA1L Specification

Fan Forced Wall Heaters - 15 KW 5100 Series Suspended Fan Forced Unit Heater - TPI F3F5115CA1L - 51.2 BTU

We have 5100 Series Suspended Fan Forced Unit Heater with 51.2 BTU and 15 KW of power. TPI F3F5115CA1L features 18 ga. steel cabinet with powder coated finish, control compartment housing a master terminal board with a hinged and latched access door; simplifying wiring, installation and maintenance. The spiral fin steel element with continuously brazed steel fins is formed to allow side draw through air flow. Louvers are individually adjustable for directional control of air flow up to 15 degree from straight horizontal.

TPI 15 KW Suspended Fan Forced Unit Heater F3F5115CA1L Specifications
UPC686334645324
KW15
BTU / H51.2
VOLTS208
PHASE3
AMPS41.7
Control Voltage24
Temperature Rise43 F
Air Throw32'
CFM1100
Recommended Mounting Height (Horizontal)11'
Recommended Mounting Height (Vertical)20'
Weight64 Lbs.

TPI 15 KW Suspended Fan Forced Unit Heater F3F5115CA1L Features:

CONSTRUCTION:

  • 18 ga. steel cabinet with powder coated finish and control compartment housing a master terminal board with a hinged and latched access door, simplifying wiring, installation and maintenance.

HEATING ELEMENT:

  • Spiral fin steel element with continuously brazed steel fins formed to allow side draw through air flow

OVERHEAT PROTECTION:

  • Equipped with automatic reset type limit.

FAN and MOTOR:

  • Totally enclosed, 1-speed, 1-phase, permanently lubricated, thermally protected motors.
  • Fan over-ride purges unit of residual heat at shutdown

LOUVER ASSEMBLY:

  • Louvers are individually adjustable for directional control of air flow up to 15 degree from straight horizontal
  • Optional diffusers available for down flow (vertical discharge) applications

TEMPERATURE CONTROLS:

  • Optional low voltage and line voltage thermostats available with an adjustable temperature range of 50 degree -90 degree F

INSTALLATION:

  • Unit Heaters can be mounted for horizontal or vertical discharge
  • Suggested for applications up to 6000 feet.

FIELD INSTALLED OPTIONS:

  • In-Built or wall mounted temperature control thermostats - low or line voltage
  • Summer fan switch to operate the fan only.
  • Power disconnect switch
  • Heat stratification thermostat
