HW
Hazardous Location Fan Forced Unit Heater
TPI

Hazardous Location Fan Forced Unit Heater

HLA122403607.524
Price $16,101.00 $10,304.64
Please select from the Options below
Factory Installed Controls
SKU: HLA122403607.524
BTU /hr.: 25600 BTU
Fuel Type: Electric
Volts: 240 V
Brand: TPI
Resources

TPI Hazardous Location Fan Forced Unit Heater HLA122403607.524 Resources:

TPI Hazardous Location Fan Forced Unit Heater HLA122403607.524 Specifications

We bring you 7500 W, 25600 BTU Hazardous Location Fan Forced Unit Heater by TPI. Model HLA122403607.524 is equipped with pressure relief valve with cintered metal mesh flame arrestor, 14 ga. steel cabinet with epoxy powder coated finish containing heater core, motor, and fan assembly and adjustable louvers allowing directional control of air flow. The manual reset capillary type high limit provides high temperature regulation and is rated for 6,000 cycles of service.

Hazardous Location Fan Forced Unit Heater - TPI HLA122403607.524 Specifications
BTU25600
Wattage7500 W
Voltage240 V
Control Volts24 V
Product Weight167 Lbs.
Phase3
Temperature Rise41.4 F
CFM580
Amperage19.4
Air Throw24'
Recommended Mounting Height8'
UPC686334734127

Hazardous Location Fan Forced Unit Heater - TPI HLA122403607.524 Features:

  • Permanently sealed, liquid to air, finned tube heat exchanger core.
  • Ethylene Glycol to water mixture uses a heat transfer fluid in the heater core, providing -49 deg. F. (-45 deg. C) freeze damage protection.
  • Manual Reset capillary type high limit provides high temperature regulation and is rated for 6,000 cycles of service.
  • 24v transformer and contactor
  • Pressure relief valve with cintered metal mesh flame arrestor.
  • 14 ga. steel cabinet with epoxy powder coated finish contains heater core, motor, and fan assembly.
  • Narrow gap safety fan guard shields all moving parts.
  • Adjustable louvers allow directional control of air flow.
  • Box lugs furnished for field connections within an approved enclosure.
  • ABS Type Approved
  • cETLus Listed
