HW
Hazardous Location Wall Convector
TPI

Hazardous Location Wall Convector

FEP08481RA
Price $1,027.95
Please select from the Options below
Factory Installed Controls
SKU: FEP08481RA
BTU /hr.: 2730 BTU
Fuel Type: Electric
Volts: 480 V
Color: Gray
Brand: TPI
Resources

Hazardous Location Wall Convector TPI FEP08481RA Resources:

Hazardous Location Wall Convector TPI FEP08481RA Specification

Electric Convection Heaters - 34" Single Phase Hazardous Location Wall Convector - TPI FEP08481RA - 2730 BTU

Offering 34" Single Phase Hazardous Location Wall Convector having 2730 Btu output power to relief from this winter. Model FEP08481RA is manufactured by top brand TPI. The heater has a power consumption of 800 watts, 480 volts and 1.7 amps. The stainless steel cartridge element inserted into aluminum finned copper sheath. The heater has heavy duty 16 ga. steel with gray epoxy textured powder coated finish. This unit is NEMA 4 rated.

Hazardous Location Wall Convector TPI FEP08481RA Specifications
UPC686334445375
Watts800
Btu's2730
Volts480
Amps1.7
Cabinet Length34"
Weight50 Lbs.

Hazardous Location Wall Convector TPI FEP08481RA Features:

  • Cabinet size 18" high, 9" wide
  • Bottom In - Front Out air flow
  • Wall mounting bracket supplied
  • Heavy duty 16 ga. steel with gray epoxy textured powder coated finish
  • 9" minimum clearance from bottom F heater to floor required
  • Stainless steel cartridge element inserted into aluminum finned copper sheath
  • Units can not be operated in room
  • Standard unit (without EPET thermostat or control section) is NEMA 4 rated ambients exceeding 104 F (40 C)
  • Units that exceed 22 Amps may not be controlled by line voltage thermostats
